All About Your ROCKMIX 10FX:

ROCKMIX 10FX - New Effects Explained:

How To Set Up Your ROCKMIX 10FX:

HOW TO MANUAL ROCKMIX 10FX:



What's in the Box:

• Mixer
• Power Adapter
• User Manual
• USB interface cable
• Bluetooth Antenna

Description:

The Rockville RockMix 10FX is the perfect solution for live bands, houses of worship, recording music, gyms, restaurants, podcasting, karaoke, and more. This mixer is packed with all of the important features that you need.

The built in effects engine on this mixer has 16 amazing sounding effects, ranging from reverbs / delays, lush choruses to voice canceller. We use a high-resolution 24 bit DSP effects processor, which makes them sound so crisp. These sound better than most external FX processors.

The built-in USB interface allows you to record the master output of all the channels to the recording software on your computer. The USB interface will also allow you to easily play back songs or other audio from your computer or laptop to channels 7 and 8 of the mixer. What is really cool is that you can EQ the sound from the mixer to get it to be exactly how you like including adding effects.

The USB interface is also perfect for podcasting. It is the bridge to get your computer audio to your speakers or to get your audio output to your computer for recording or live streaming.

Our low-noise mic pre-amp is clean, with a lot of headroom, ensuring a clear sound. Mic pre-amps are one of the most important parts of a mixer. A good quality pre-amp such as this one makes a world of a difference in the sound.

The 3-band EQ and panning allows you to customize the sound the way you want it. The FX send feature lets you connect external effects to the console in order to further shape and enhance your sound. We added pro Bluetooth connectivity, so you can have wireless playback whether you're in a gym, restaurant, home, or any other place where you do not want to hardwire your playback device. The Bluetooth is also a great way to have guests call to your podcast show. We added an external bluetooth antenna for a reliable connection.

We added a high quality compressor to channels 1 and 2 which is great for podcasts, singers, and drummers. A compressor is used to balance the dynamic range of your signal, so this way, the louder and quieter parts of the signal are all sounding perfect. What a compressor does is it allows you to set a minimum and maximum threshold for your audio signal. We accomplish this with just one knob making it really easy to use. If you are doing a podcast and you might have parts with whispering and other parts where people are yelling. A compressor will make the podcast sound really professional. It will make the whispering easy to hear and it will lower the yelling to a normal usable range that sounds good on all speakers. It helps to avoid clipping as well. Another great use is for singers or drummers during live shows or recordings. The compressor will really fine tune the sound and make it sound even and balanced by avoiding potential clipping/distortion of your loud signals (kicks, snare hits, loud vocal passages etc.) Compression is also great for singers because if you sing softly into the mic, it will make those soft passages sound clear and level with the rest of your mix. Please keep in mind you can set the level of compression or turn it off. Our one knob compression is also really easy to use and set.

Channels 1 through 4 are loaded with XLR and ¼" combo jack inputs. Then you get 2 stereo channels that can accept a variety of sources ranging from microphones to any mono/stereo instruments. Channels 1 through 4 all have 48V phantom power for use with condenser mics.

Channels 5 through 8 are your stereo channels and they have 2 band EQ, effects and balance. These channels can accept a variety of sources ranging from microphones to any mono/stereo instruments.

Channels 9-10 is your RCA tape input which is perfect for any device. It is a basic stereo channel with level controls that can be routed either to your monitor or your master mix output which is really cool.

The clipping indicators will prevent you from adding too much gain, making it easy to set your levels accurately.

This solid steel mixer is built like a Rock! Every component, including all potentiometers and knobs are extremely high grade.

If you are using this for Karaoke you will love our vocal canceller function that will remove the vocals so you can sing along to the music!

Features:

• Rockville RockMix 10FX 10 Channel Mixer with USB Recording Interface, Effects and Bluetooth
• Channels 1 and 2 have XLR / ¼" Mic/Line input combo jacks with gain and volume control, 3-band EQ, pan, 48V phantom power, pad, high pass filter, FX and compressor
• Channels 3 and 4 have XLR / ¼" Mic/Line input combo jacks with gain and volume control, 3-band EQ, pan, 48V phantom power, pad, high pass filter, FX
• Channels 5 - 8 have ¼" line input jacks with volume control and 2 band EQ, FX and can accept balanced and unbalanced signals and 6 have ¼" inputs
• Channels 9-10: TAPE Input with RCA inputs and level control assignable to either headphone or main output
• USB audio interface assignable to channels 7-8 with 2 band EQ, FX, balance controls
• RCA main mix output with volume control (to plug into your monitors)
• XLR Main mix balanced output
• ¼" Main mixed unbalanced output
• ¼" Headset and Monitor output
• 24 Bit FX engine with 16 DSP Effects (Each effect sounds great)
• Vocal Canceler feature for Karaoke applications
• Effect mute button (controllable with an optional footswitch)
• Built in professional Bluetooth wireless audio streaming
• Main mix master volume knob
• Built in USB interface will send the Summed Stereo Mix to your favorite DAW
• Interface will be identified and addressed as an external sound card in your DAW
• Peak LED indicator detects clipping on channels 1-4
• Main mix has left and right clip indicators
• Power on LED indicator
• Super linear mic preamp with low noise (this uses a top of the line mic pre normally found in very expensive mixers)
• This mixer is built out of solid steel metal and when you pick it up you immediately can feel the weight and how solid it is
• All knobs and potentiometers are super sturdy and linear
• 48V phantom power for condenser microphones
• Stereo return knob
• Rubber feet
• Mixer includes a power adapter DC5V/1A
• British EQ circuitry is designed to emulate the classic EQ from the legendary mixers that came out in the 1950's, 60's and 70's
• Dimensions: (L x W x H) 12.13" x 9.84" x 2.44"

Sensitivity/ Impedance:

• Mic(1-4): 3mV/5.3KO (Gain max)
• Line, channel 1-4 (Balanced): 15mV/24KO (Gain max)
• Line, channel 1-4 (Unbalanced): 15mV/12KO (Gain max)
• Line, channel 5-8/ STEREO/RETURN (Balanced): 300mV/44KO
• Line, channel 5-8/ STEREO/RETURN (Unbalanced): 300mV/22KO
• TAPE channel: 300mV/20KO
• Output level: 5.8V max (MAIN; MONITOR; TAPE)
• Frequency range: 20 -25000 Hz
• THD: =0.05%
• S/N ratio: 88dB
• Equalizer
• Bass range: ±15dB/80Hz
• Mid range: ±15dB/2.5KHz
• High range: ±15dB/12kHz
• Headphone impedance: =16O
• USB interface: USB 2.0 full speed and earlier (also 1.1 compatible)
• 16-Bit Delta-Sigma, 44.1kHz Sampling rates; 48khHz max,
• Bluetooth: Compliant with Bluetooth Specification V5.0 + EDR
• Phantom power for Combo jack: 48V
• Power supply via power supply unit provided and connected to AC100-240V 50/60Hz
• Dimensions: 385 (L) *295 W) *115 (H) mm
• Weight: 4.85LBS(2.2KG)
• Suitable operating system for data transfer via USB interface:
• Windows 2000, XP or higher; Mac OS 9.0.4 or higher, 10.X or higher.
