Videos of dB45:

Description:

The dB45 is a 4 channel amplifier with 3,200 watts peak output and 800 watts Dyno Certified power. Here at Rockville we offer the best value in car audio. We therefore want to make it easy for you to compare our products to any brands on the market. The peak rating can be used to compare with brands who use peak ratings such as Boss and Power Acoustik while the Dyno Certified RMS rating can be used to compare with top brands such as Kicker, Rockford, Alpine, etc.

This amp has a fully adjustable 12dB/Octave crossover with differential circuitry. Other features include a subsonic filter, a fully adjustable bass equalizer, and mute and delay soft start technology. The dB45 is protected by a full IC controlled circuit and has professional peak limiter circuitry guaranteeing distortion free music playback at all levels.

The dB amps by Rockville use the top parts and components recommended by Rockville’s very own engineer. These amps are the best sounding out of any series we have ever created. They perform more efficiently resulting in even dB of sound. We created them to be 2 ohm stable just like the world’s most famous amps by Rockford Fosgate, Kicker, etc. If you compare our amp to the most famous amps you will find our amp can compete and, in my opinion, surpass the performance of anything in its class.

Each and every amplifier we manufacture is tested twice. Once at the semi-finished PCB stage of production, and then another test is done at the final assembly. We also run age tests on them. After this is all done, we hire a 3rd party independent company unaffiliated with our factory or with us to go to the factory and inspect 20% of all the production items. We test the power, the controls, and over 20 other tests. We guarantee these amps will satisfy you. We are so confident in your satisfaction of this amplifier that we will offer you a 90 day money back guarantee. If this amp does not perform as well as you expected we will send you a pre-paid shipping label and give you all of your money back. This means if for any reason you want to return the amplifier back for a full refund within 90 days, you can! (Amp must be complete along with the box).

Includes:

• Amplifier

• Birth sheet with tested power

• Owner’s manual

• Mounting Screws

• Warranty

Features:

• Rockville dB45 3200 Watt/800 Watt Dyno-Certified RMS 4 Channel Amplifier Car Stereo Amp, Loud!!

• Dyno Certified RMS Power Ratings: (Certified Dyno Test / Less than 1 % THD) (Use these ratings when comparing with top brands such as Kicker, Rockford Fosgate, etc)
  - 2 Ohm: 200 Watts x 4 Channel <1% THD+N
  - 4 Ohm:135 Watts x 4 Channel <1% THD+N
  - 4 Ohm Bridged: 400Watts x 2 Channel<1% THD+N

• Peak: (Use these ratings when comparing with the top budget brands such as Boss, Power Acoustik, etc)
  - 2 Ohm: 800 Watts x 4 Channel
  - 4 Ohm:540 Watts x 4 Channel
  - 4 Ohm Bridged: 1600 Watts x 2 Channel

• High-Speed MOSFET Power Supply

• Under Voltage Protection at 10V

• Over Voltage Protection at 16V

• Tertiary Supplies Circuitry

• Optical Coupler Class “AB” Technology

• Studio-Grade Bipolar Output Stage Transistors

• Fully Adjustable 12dB / Octave Crossover with Differential Circuitry

• Low Pass Filter: 50Hz – 3KHz

• High Pass Filter: 15Hz - 1KHz

• Full IC-Controlled Protection Circuitry

• Fully Adjustable 12dB Bass Equalizer

• Mute and Delay Soft Start System

• 8 Volt Preamp Circuitry

• Status Mode LED Indicator

• Minimum THD at Rated Power: < 0.05%

• S / N Ratio: >90dB

• Frequency Response: 10Hz - 50KHz

• Damping Factor: >150 @ 100Hz

• 35 Amp*3 ATC Fuse

• Dimensions: (W x H x L) 9" x 2.4" x 21.0"
